Jinan Diesel Engine Jichai B6190 G6190 Spare Parts Supplier

Brand Name : jichai

Model Number : 6190

Certification : ce

Place of Origin : china

Contact Now

Jinan Diesel Engine Jichai B6190 G6190 Spare Parts Supplier

Jinan Diesel Engine Jichai B6190 G6190 Spare Parts Supplier



6 in-line marine diesel engines


ModelRated Power(kw/hp)Rated speed(r/min)Specific fuel consumption(g/kw’h)Specific oil consumption(g/kw’h)Overall dimension L*B*H(mm)Net weight(kg)
6190ZLC450/6101450≤ 204≤ 1.22990*1243*17633960
6190ZLC-1400/5401200≤ 204≤ 1.22990*1243*17633960
6190ZLC-2330/4501000≤ 204≤ 1.22990*1243*17633960
6190ZLC-3400/5401300≤ 204≤ 1.22990*1243*17633960
B6190ZLC450/6101450≤ 204≤ 1.23000*1324*18203960
B6190ZLCZ-R450/6101450≤ 204≤ 1.23000*1324*18203960
B6190ZLC-1400/5401200≤ 204≤ 1.23000*1324*18203960
B6190ZLCZ-1R400/5401200≤ 204≤ 1.23000*1324*18203960
B6190ZLC-2330/4501000≤ 204≤ 1.23000*1324*18203960
B6190ZLCZ-2R330/4501000≤ 204≤ 1.23000*1324*18203960
B6190ZLC-3400/5401300≤ 204≤ 1.23000*1324*18203960
B6190ZLCZ-3R400/5401300≤ 204≤ 1.23000*1324*18203960
G6190ZLC540/7401450≤ 204≤ 1.22995*1259*17544500
G6190ZLCZ-R540/7401450≤ 204≤ 1.22995*1259*17544500
G6190ZLC-R540/7401450≤ 204≤ 1.22995*1259*17544500
G6190ZLCZ540/7401450≤ 204≤ 1.22995*1259*17544500
G6190ZLC-1450/6101200≤ 204≤ 1.22995*1259*17544500
G6190ZLCZ-1R450/6101200≤ 204≤ 1.22995*1259*17544500
G6190ZLC-1R450/6101200≤ 204≤ 1.22995*1259*17544500
G6190ZLCZ-1450/6101200≤ 204≤ 1.22995*1259*17544500
G6190ZLC-2380/5201000≤ 204≤ 1.22995*1259*17544500
G6190ZLCZ-2R380/5201000≤ 204≤ 1.22995*1259*17544500
G6190ZLC-2R380/5201000≤ 204≤ 1.22995*1259*17544500
G6190ZLCZ-2380/5201000≤ 204≤ 1.22995*1259*17544500
G6190ZLC-3480/6501300≤ 204≤ 1.22995*1259*17544500
G6190ZLCZ-3R480/6501300≤ 204≤ 1.22995*1259*17544500
G6190ZLC-3R480/6501300≤ 204≤ 1.22995*1259*17544500
G6190ZLCZ-3480/6501300≤ 204≤ 1.22995*1259*17544500
Main technical data
No. and arrangement of cylinders:6-cylinder,in-line
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:35.73L
Compression ration:14:1(6190,B6190),14.5:1(G6190)
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
